Specification

Image Sensor 3K CMOS

Signal System PAL/NTSC

Resolution 2960 (H) × 1665 (V)

Frame Rate

TVI: 3K@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps

AHD: 5 MP@20fps, 4 MP@25fps/30fps

CVI: 4 MP@25fps/30fps

CVBS: PAL/NTSC

Min. Illumination 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light

Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s

Lens 2.8 mm and 3.6 mm fixed focal lens

Field of View

2.8 mm, horizontal FOV: 102°, vertical FOV: 56°, diagonal FOV: 122°

3.6 mm, horizontal FOV: 80°, vertical FOV: 45°, diagonal FOV: 96°

Lens Mount M12

Light Alarm Solid Light Alarm (White Light)

Day & Night 24/7 Color Imaging

WDR (Wide Dynamic Range) Digital WDR

Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°


White Light Auto/Off

Image Mode STD/HIGH-SAT/HIGHLIGHT

AGC Yes

Day/Night Mode Color

White Balance Auto/Outdoor/Global/Manual

AE (Auto Exposure) Mode DWDR,BLC,HLC,Global,HLS

Noise Reduction 2D DNR

Language English

Function

Brightness,Contrast,Mirror,Defective Pixel Correction,Sharpness,Anti-Banding,Smart

Light

Interface

Video Output Switchable TVI/AHD/CVI/CVBS

Audio In Built-in mic

General

Operating Conditions -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)

Power Supply

12 VDC ± 25%,

*You are recommended to use one power adapter to supply the power for one camera.

Consumption Max. 3.5 W

Protection Level IP67

Material Main body: Metal, Enclosure: Plastic

White Light Range Up to 40 m

Communication HIKVISION-C

Dimension Φ 109.98 mm × 98.27 mm (Φ 4.33" × 3.87")

Weight Approx. 318 g (0.70 lb.)
