Hikvision DS-D5043UC

Hikvision DS-D5043UC 42" cctv monitor
Hikvision Products

Hikvision DS-D5043UC

42.5" LCD Monitor

  • Key Features
  • Designed for surveillance, high reliability, and stability.
  • 42.5" LED backlight with wide display equipment
  • 4K resolution is 4 times the resolution of 1080p, providing a wider view and finer detail
  • Multiple inputs: HDMI, VGA, RJ45, USB
  • Narrow front bezel
  • Wide view angle: Horizontal 178°, Vertical 178°
  • 24/7 operation.
  • 3 year warranty




Hikvision DS-D5043UC 42" cctv monitor

Share the love with your friend

Complete the form below and we'll email your friend about this product

You’ll earn 0 reward points with this purchase.

Be one of the first to know!

We’re sorry we’re out of stock but we can let you know as soon as it's available if you enter your email address below.

The Hikvision DS-D5043UC is a 43-inch LED-backlit monitor designed for video surveillance applications. It has a 4K Ultra HD resolution of 3840x2160 pixels and a 16:9 aspect ratio, providing a clear and detailed image display.

The monitor features a 178-degree viewing angle, allowing for consistent viewing from different angles. It also supports 3D comb filter and deinterlace, which enhance the quality of the displayed video.

The DS-D5043UC has multiple input interfaces including VGA, HDMI, and BNC, allowing for flexible connectivity options. It also has built-in speakers, which provide a complete video display solution.

In addition, the monitor is designed with a durable metal casing, making it suitable for use in a variety of settings. It also has VESA mounting holes for easy installation and wall mounting.

The DS-D5043UC also features 3D digital noise reduction, which helps to reduce image noise and improve image quality. It also has a programmable on/off schedule, allowing for energy-saving and convenient use.

Hikvision DS-D5043UC is a reliable and high-resolution monitor for use in video surveillance applications, offering flexible connectivity options, durable construction, and advanced features such as 3D digital noise reduction and programmable on/off schedule. The large 43-inch size and 4K Ultra HD resolution provide a wider and more detailed viewing area, making it suitable for monitoring larger spaces.


Model DS-D5043UC


Viewing Angle 178° (H) / 178° (V)

Screen Size 42.5 inch

Active Display Area 941.184 mm (H) × 529.416 mm (V)

Backlight D-LED

Pixel Pitch 0.2451 mm (H) × 0.2451 mm (W)

Resolution 3840 × 2160

Brightness 400 cd/m² (Typ.)

Colour Depth 1.07 billion

Contrast Ratio 1200:1

Response Time 8 ms


Video & Audio Input HDMI × 2, VGA × 1, AUDIO IN × 1

Video & Audio



Network Interface LAN × 1

Data Transmission


USB 2.0 × 1, USB 3.0 × 1

Control Interface RS-232 × 1

Loudspeaker 8 W × 2


Power Supply 100 to 240 VAC, 50/60 Hz

Power Consumption ≤ 120 W

Standby Consumption 0.5 W



Working Temperature 5°C to 40 °C(41 °F to 104 °F)

Working Humidity 20% to 80%RH (No Condensation)

Storage Temperature -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)

Storage Humidity 10% to 90%RH (No Condensation)


VESA 200 mm × 200 mm/400 mm × 400 mm

Product Dimensions

(W × H × D)

968.2 mm × 559.4 mm × 60.9 mm(38.12'' × 22.02'' × 2.40'')

Mounting Type Wall mounting

Package Dimensions

(W × H × D)

1070 mm × 696 mm × 159 mm( 42.13'' × 27.40'' × 6.26'')

Net Weight 8.6 kg (18.96 lb.)

Gross Weight 11.7 kg (3.75 lb.)

Packing List Power cable × 1, HDMI cable × 1, remote control × 1, user manual × 1


If the appearance and parameters in this specification vary from the actual product, the later prevails. You can also consult local sale staff.

Colour Black

PDFSpec Sheet
