Hikvision 16ch TURBO ACUSENSE DVR iDS-7216HUHI-M2/S(E)
Hikvision Products


HIKVISION 16-ch 5 MP 1U H.265 AcuSense DVR

Deep learning-based motion detection 2.0 for all analogue channels

Deep learning-based perimeter protection

Efficient H.265 pro+ compression technology

Encoding resolution 8 MP@8 fps/5 MP@12 fps/3K@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps

5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)

Up to 32 network cameras can be connected

Compression and Recording

H.265 Pro+ video compression improves encoding efficiency, and reduces data storage costs

Recording at up to 8mp resolution

Storage and Playback

2 SATA interfaces

Smart search for efficient playback

Smart Function

Deep learning-based motion detection, and perimeter protection (line crossing and intrusion detection)

Support multiple VCA (Video Content Analytics) events for both analog and smart IP cameras

Network & Ethernet Access

Compatible with major Wi-Fi dongle products in the market

Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management

Output bandwidth limit configurable


Hikvision 16ch TURBO ACUSENSE DVR iDS-7216HUHI-M2/S(E)

Share the love with your friend

Complete the form below and we'll email your friend about this product

You’ll earn 0 reward points with this purchase.

Be one of the first to know!

We’re sorry we’re out of stock but we can let you know as soon as it's available if you enter your email address below.

Hikvision iDS-7216HUHI-M2/S(E) is a digital video recorder (DVR) designed for use in surveillance systems. It is part of Hikvision's Turbo HD 4.0 product line, which supports both analog and high-definition (HD) cameras.

Here are some key features and specifications of the Hikvision iDS-7216HUHI-M2/S(E):

Camera Inputs: This DVR supports up to 16 video channels, allowing you to connect and record footage from up to 16 cameras simultaneously.

Video Resolution: It supports various video resolutions, including HD-TVI, AHD, CVI, and CVBS. The maximum supported resolution is 8MP for HD-TVI cameras and 2MP for AHD, CVI, and CVBS cameras.

Compression: The DVR uses H.265+ video compression technology, which helps reduce bandwidth and storage requirements while maintaining high-quality video.

Storage: It has multiple storage options, including internal hard drives. The number of supported hard drives and their capacity may vary depending on the specific model or variant.

Recording Modes: The iDS-7216HUHI-M2/S(E) supports various recording modes, including continuous, scheduled, motion detection, and event-triggered recording.

Network Connectivity: It has built-in Ethernet ports for connecting the DVR to your local network, allowing for remote access and management of the surveillance system. It also supports mobile viewing through compatible Hikvision mobile apps.

HDMI and VGA Outputs: The DVR provides HDMI and VGA video outputs, allowing you to connect it to a monitor or display for local video playback and live viewing.

Audio Input and Output: It features audio input and output ports, enabling you to connect audio devices for audio recording and playback.

Alarm I/O: The iDS-7216HUHI-M2/S(E) has alarm input and output ports, allowing integration with external sensors and devices for alarm triggering and response.

Note: 1: Motion detection 2.0 and perimeter protection cannot be enabled at the same time. Enable one function will make the other one unavailable.

2: Enhanced IP mode might be conflicted with smart events (face picture comparison, motion detection 2.0 and perimeter protection) or other functions, please refer to the user manual for details.

3: The number of audio inputs and alarm in/out can be optional. The tag on the package will describe audio input and alarm in/out parameters. For example, “4A+8/4ALM” means your device has 4 audio inputs, 8 alarm inputs and 4 alarm outputs.

If your device only has 1 audio input, the tag may not describe it.


PDFSpec Sheet
