Multimedia Solutions

MMS 3 x 1 HDMI 4K Switch UHD

Vision MM20-301U - 3 x 1 HDMI GREEN Series 4K Switch
Multimedia Solutions

MMS 3 x 1 HDMI 4K Switch UHD

ULTRA HD 3 x 1 HDMI source switch HDMI 2.0v HDCP2.2 4K2K 60Hz (fps) 12 bit.

Compact UHD 4K switch that provides fast and uncomplicated switching between three 4K Ultra-HD HDMI video sources and the HDMI output.

  • Provides high speed switching between three 4K Ultra-HD HDMI video sources
  • Supports 3D and HDTV resolutions up to UHD @30Hz and 4K2K @60Hz
  • Dolby TrueHD, Dolby Digital, DTS 5.1, Dolby Digital+, DTS Master Audio, Dolby Atmos, and LPCM 7.1 channel digital audio formats
  • 18Gb/s video bandwidth (600MHz)
  • Compliant with HDMI 2.0b and HDCP 2.2
  • Intuitive operation with remote control
  • Dimensions (HxWxD): 16x200x79mm
£0.00
£43.86

QTY


Vision MM20-301U - 3 x 1 HDMI GREEN Series 4K Switch

Share the love with your friend

Complete the form below and we'll email your friend about this product


You’ll earn 0 reward points with this purchase.

Be one of the first to know!

We’re sorry we’re out of stock but we can let you know as soon as it's available if you enter your email address below.

This 3 x 1 HDMI 4K Switch UHD from Multimedia Solutions is an HDMI switch with three inputs and one output, designed to allow you to switch between multiple HDMI sources on a single display. This switch supports UHD/4Kx2K resolution, which means it can handle high-definition video with a resolution of up to 3840 x 2160 pixels. The switch is designed to be compact and easy to use, with automatic switching and a remote control for added convenience. It is a useful device for anyone who needs to connect multiple HDMI sources to a single display, such as a TV, projector, or monitor.


  • Model MM20-301B 3 x 1 UHD HDMI source switch
  • Input 3 HDMI female inputs
  • Output 1 x HDMI female output
  • HDCP Protocol HDCP 2.2
  • HDMI format HDMI 2.0
  • Resolution support (1) 4K2K @30Hz 24bit colour depth
  • Resolution support (2) 4K2K @60Hz 12bit colour depth 3D frame sequential video format 1080p @ 60Hz
  • Digital Audio Format Dolby True HD DTS-HD Master Audio LPCM 7.1CH
  • Video Bandwidth 300MHz / 10.2Gbps
  • LED Indicators Power, In 1, In 2, In 3 input indicators
  • Manual / IR Control Manual switch + 38KHz IR remote control and sender included in delivery
  • Power requirement 5V /1.0A DC Power supply included in delivery
  • ESD Protection ±8kV (air gap discharge) : ±4kV contact discharge
  • Dimension / Weight 64mm x 155mm x 17mm / 180g
  • Operation temperature -200C to +600C

PDFSpec Sheet
