Chester Digital Supplies Ltd

Cat5e Indoor Copper Cable 305m

4 Pair Grey PVC Sheath 305m box
Chester Digital Supplies Ltd

Cat5e Indoor Copper Cable 305m

CAT5e Grey Pvc 24AWG, (UTP) 305m

Solid copper conductor, unscreened twisted pair 4 Pair Grey PVC Sheath 10000ft / 305M box

– For indoor use

– For use in computer networking and internet service installations

– For commercial and residential applications

– Can be used in the place of CMR, CMG, CM and CMX cable

– CAT.5e is also used to carry other signals such as telephony and video.

Inner conductor Ø:          24 AWG(0.48 mm)

Conductor material:        Solid bare annealed copper

Core insulation: PE | Polyolefin

Colour Code:

Pair 1: Blue-White/Blue

Pair 2: Orange-White/Orange

Pair 3: Green-White/Green

Pair 4: Brown-White/Brown

Outer sheath material:   PVC

Outer diameter:               app. 5.1 mm

Outer sheath colour:       Grey / Other colours can be order at request.

£0.00
£88.62

QTY


4 Pair Grey PVC Sheath 305m box

Share the love with your friend

Complete the form below and we'll email your friend about this product


You’ll earn 0 reward points with this purchase.

Be one of the first to know!

We’re sorry we’re out of stock but we can let you know as soon as it's available if you enter your email address below.

Cat5e Indoor Copper Cable 305m is a type of network cable commonly used for Ethernet networks. It consists of four pairs of twisted copper wires, encased in a protective jacket for indoor use. The "Cat5e" in its name stands for "Category 5 enhanced," indicating that it meets certain performance standards for data transmission.

The cable has a length of 305 meters, making it suitable for large-scale installations in homes, offices, and other indoor environments. It can be used to connect computers, servers, routers, switches, and other network devices, providing reliable and fast data transfer rates.

When installing Cat5e Indoor Copper Cable, it is important to follow proper techniques to ensure maximum performance and avoid interference. This may include proper termination, cable management, and grounding.

Dimensions

Length: 305m/1000ft

Cable weight:    8.8kg

Wire size:            24AWG (Ø 0.48mm)

Overall diameter of insulation:   0.88mm

Overall outside diameter:             5.1 mm



Electrical characteristics

ANSI/TIA Category          5e

Characteristic Impedance (Frequency: 1-200 MHz)


100 ± 15 ohms

DC Resistance Unbalance, maximum       5 %

DC Resistance , maximum at 20˚C              9.38 ohms/100 m

Propagation delay at100 MHz (ns/100m)               <536

Delay Skew         ≤35 ns

Mutual Capacitance        5.6 nF/100 m @ 1 kHz

Nominal Velocity of Propagation (NVP)  69%

Coupling attenuation at 30˚C       45MHz(dB)

Operating Frequency, maximum               150 MHz

Safety Voltage Rating     300 V

Dielectric Strength, minimum     1500 Vac | 2500 Vdc




Mechanical Properties

Maximum operating temperature:           70˚C

Operating Temperature Range: -20˚C to 60˚C

Installation temperature:             0˚C to 60˚C

Minimum bending radius:            4 x cable diameter

Maximum pulling force  100 N
