Supercharge your wired expansion

Expand the security system for whatever need or requirements with eight additional inputs. Self-powered and security assured, the PCX RIX8+PSU seamlessly adapts the system to suit.

  • RS485 Expander
  • 8 Double Pole or Double EOL Inputs + 3EOL
  • 4 Transistor Outputs
  • Integrated 2.5A power supply
  • Complies with EN50131-1

Trade log in



Pyronix Input Expansion Module || EURO-ZEM8+PSU

Share the love with your friend

Complete the form below and we'll email your friend about this product

You’ll earn 0 reward points with this purchase.

Be one of the first to know!

We’re sorry we’re out of stock but we can let you know as soon as it's available if you enter your email address below.

Deliver the security the installation needs with the ability to add eight wired inputs, This provides the ultimate  ability to seamlessly expand the system.

The PCX RIX8+PSU supports wired double pole or double EOL inputs. Deliver the output the installation needs with the ability to add four wired outputs The ability to add four transistor outputs provides greater ability and options to any install, adding a multitude of peripherals to deliver the perfectly tailored system.

Extend the data BUS range with the integrated RS485 repeater Supercharge your installation by extending the RS485 BUS, for those bigger installs that need more power and more range.

Beat the burglar with front & rear tamper protection This ensures that maximum security is maintained against accidental or malicious tampering of the system, providing that added peace of mind that the system is secure.

Meet the required security standard with Grading options The PCX RIX8+PSU is Grade 3 for the superior security the installation needs. Has its own power with an integrated 2.5A intelligent PSU Provides the ability to monitor its own power from the PSU.

All connections are automatically made to draw their power from the power supply and it can be used to monitor if there is an issue at that particular point

  • Metal housing    Yes
  • Tamper protection    Yes
  • Integrated RS485 repeater for extending data bus range    Yes
  • Inputs & outputs
  • Wired EOL inputs    8
  • Wired double pole inputs    8
  • Total inputs    8
  • Outputs on board    4
  • Environmental and operating features
  • Certified operating temperature    -10 to +40C
  • Nominal operating temperature    -10 to +40C
  • Physical dimensions (H x W x D)    390mm x 310mm x 80mm
  • Weight    1062g
  • Electrical & battery
  • Integrated power supply    2A
  • Battery capacity    700mA (8A to 17A)
  • Battery supply protection    Reverse polarity protected
  • Battery low voltage protection    10.5v low voltage cut off
  • Internal battery charger    800mA Continuous, 13.68V nominal (fold-back current limited)
  • Recharge time    <24 hours
  • Mains supply    230v (220-240v) AC Max 250mA
  • Operating voltage    11-15v DC
  • Current limit    400mA
  • Certifications and warranty
  • Security Grade    Grade 3
  • Environmental class    II
  • EN Certificate    EN50131-3:2009 | EN50131-1:2006+A1:2009 | PD6662:2010
  • Certification type    IMQ
  • Certificate number    CA12.01431
  • Electrical conformity    CE
  • Warranty    2 years
