Triax Topaz

3 input - FM / DAB / UHF Multiband Amplifier

Triax Topaz is a multiband launch amplifier used in television signal distribution systems. It's designed to boost and distribute TV signals from an aerial to multiple points in a building.

  • 3 input Multiband Amplifier
  • Variable Gain Control 0-20 dB on All Inputs
  • Switchable Filtering Control
  • Masthead Line Power Supply with Short Circuit Protection
  • Test -30dB
  • Earth Bonding Point

SKU:-371007

Trade log in

£0.00
£55.99

QTY


TOPAZ - 3 input - FM/DAB/UHF Multiband Amplifier

Share the love with your friend

Complete the form below and we'll email your friend about this product


You’ll earn 0 reward points with this purchase.

Be one of the first to know!

We’re sorry we’re out of stock but we can let you know as soon as it's available if you enter your email address below.

Multiband: It can amplify signals across different frequency bands, including FM radio, DAB radio, and UHF television.

Launch Amplifier: It's typically installed at the "head" of the distribution system, where the signal first enters the building. Its job is to provide a strong signal to feed the rest of the system.

LTE 700: This indicates that it's designed to filter out interference from the 700MHz frequency band, which is now used for 5G mobile services. This ensures that your TV signal isn't disrupted by 5G transmissions.

Variable Gain Control: Allows you to adjust the amplification level to optimize the signal strength for your specific installation.

Masthead Line Power Supply: It can be powered remotely via the coaxial cable, simplifying installation.

Short Circuit Protection: Protects the amplifier from damage in case of a short circuit in the cabling.

Test Output: Provides a convenient point to measure the signal strength.

Earth Bonding Point: Ensures safe grounding of the amplifier.

In simpler terms: Imagine the Triax Topaz as a booster for your TV signal. It takes the signal from your aerial, makes it stronger, and then sends it to all the TVs in your house. The "LTE 700" part means it's designed to work well even with 5G phones around.

If you're looking to improve your TV reception, especially if you have multiple TVs or live in an area with a weaker signal, a launch amplifier like the Triax Topaz could be a good solution.


ORDER INFORMATION

EAN Number      5702663710078

FREQUENCY RANGE

Frequency range              88...694 MHz

Frequency Range DAB    217...230 MHz

Frequency Range FM      88...108 MHz

Frequency range UHF     470-694 MHz

LOSS

Attenuation - adjustable               0-20 dB

GAIN

Gain       30 (FM/DAB) dB

Gain - UHF          34 dB

Noise figure VHF               <7 dB

Noise figure UHF              <7 dB

CONNECTORS

Number of inputs             3

Number of outputs         2 (Full and Test)

CHARACTERISTICS

Test Point            - 30 dB

ELECTRICAL

Impedance         75 Ω

OPERATIONAL

LED indicator      Yes

AC Supply voltage            230/50Hz VAC

Power Consumption (typ.)           5 W

LINE power DC voltage (max.)    12 Switchable VDC

LINE power current (max.)           100 mA

MECHANICAL

Product Length 190 mm

Product Width   135 mm

Product Depth   55 mm

Packaging Height              0.060 m

Packaging Width               0.200 m

Packaging Depth              0.190 m

Packaging Volume           0.002 m3

Net Weight         0.790 kg

Tara Weight       0.100 kg

Total Weight      0.890 kg

Remarks              Screened amplifier
